Part Name
|
OEM Number
|
Remarks
|
|
Complete Assembled Cylinder Head (With Camshafts, Valves & Rockers)
|
11110-82602
|
Full assembled head exclusive for G13B 16V DOHC
|
|
Bare Cylinder Head Shell (No Valve Train)
|
11110-57802 / 11100-52G01
|
Empty aluminum head housing for remanufacturing
|
|
Intake Camshaft Assembly
|
12710-52G00
|
DOHC intake camshaft for G13B high-rev engine
|
|
Exhaust Camshaft Assembly
|
12720-52G00
|
Matching exhaust camshaft, interchangeable with G13BB
|
|
Single Intake Valve
|
12911-60B00
|
Standard size intake valve per cylinder
|
|
Single Exhaust Valve
|
12912-60B00
|
Standard size exhaust valve per cylinder
|
|
Valve Stem Oil Seal (Intake & Exhaust Universal)
|
09289-52001
|
Single oil seal for each valve stem
|
|
Inner & Outer Valve Spring Set
|
12921-60B00
|
Complete dual spring assembly for one valve
|
|
Full Cylinder Head Bolt Kit (10 Pcs)
|
09103-52002
|
Torque-to-yield stretch head bolts, one-time use
|
|
Valve Guide Sleeve
|
11131-60B00
|
Replacement valve guide for engine overhaul
|
|
Part Name
|
OEM Number
|
Remarks
|
|
Complete Forged Crankshaft Assembly
|
12221-52G00
|
G13B exclusive crankshaft, not interchangeable with G13A
|
|
Standard Main Bearing Set (STD, 5 pairs upper & lower)
|
12300-52G00
|
Full set crankshaft main bearings
|
|
Crankshaft Thrust Washer Set
|
12305-52G00
|
Axial positioning thrust shims for crankshaft
|
|
Single Complete Connecting Rod
|
12160-52G00
|
4 reinforced forged rods total for 4 cylinders
|
|
Standard Connecting Rod Bearing (STD single pair)
|
12170-52G00
|
Big end bearing for single connecting rod
|
|
Connecting Rod Bolt (Single Fastener)
|
09104-52001
|
High tensile rod cap bolt
|
|
STD Complete Piston (With wrist pin & circlip)
|
12100-52G00-000
|
Flat-top STD piston for G13B 16V engine
|
|
Single Cylinder Piston Ring Set (3 Rings)
|
12140-52G00
|
2 compression rings + 1 oil control ring
|
|
Piston Wrist Pin
|
12151-52G00
|
Pin connecting piston and connecting rod
|
|
Part Name
|
OEM Number
|
Remarks
|
|
Full Engine Overhaul Gasket Kit (All Upper & Lower Seals)
|
11402-61861
|
Includes oil pan gasket, front/rear crankshaft oil seals, all small gaskets
|
|
Valve Grind Top Gasket Set (Cylinder Head Only)
|
11400-61812
|
Only for cylinder head disassembly, excludes oil pan gasket
|
|
MLS Cylinder Head Gasket
|
11141-82000
|
Multi-layer steel reinforced head gasket
|
|
Rubber Valve Cover Gasket
|
11189-60B00
|
Full perimeter valve cover sealing gasket
|
|
Intake Manifold Gasket Set
|
13119-60B00
|
Full gasket set for twin runner intake manifold
|
|
Exhaust Manifold Gasket
|
14140-60B00
|
Single exhaust manifold sealing gasket
|
|
Front Crankshaft Oil Seal (Timing Gear Side)
|
09283-52002
|
Timing end crankshaft oil seal
|
|
Rear Main Crankshaft Oil Seal (Flywheel Transmission Side)
|
09283-60B01
|
Large rear crankshaft oil seal
|
|
Oil Pan Rubber Gasket
|
11138-60B00
|
Seal gasket for stamped steel oil pan
|
|
Part Name
|
OEM Number
|
Remarks
|
|
Primary Timing Chain
|
12761-52G00
|
Silent timing chain connecting crankshaft & dual camshafts
|
|
Hydraulic Timing Chain Tensioner
|
12831-52G00
|
Automatic hydraulic chain adjuster
|
|
Timing Chain Guide & Damper Rail Kit
|
12811-52G00
|
Upper & lower sliding timing guides
|
|
Complete Engine Oil Pump Assembly
|
16100-82811
|
Front-mounted rotor oil pump with pressure regulator valve
|
|
Camshaft Oil Seal
|
09289-52002
|
Oil seal for intake/exhaust camshaft front end
|
G13B is factory fitted for Suzuki Swift GTi, SJ413 Samurai, Jimny 1300, Cultus, Geo Metro for Southeast Asia, Europe & North American export markets.
