Part Name
|
OEM Number
|
Remarks
|
|
Complete Assembled 8V Cylinder Head (With Camshaft, Valves & Rockers)
|
11110-61A00
|
SOHC 8-valve head for early G16A
|
|
Complete Assembled 16V Cylinder Head (DOHC Full Assembly)
|
11110-60A00
|
16-valve dual cam head, casting mark 57B
|
|
Bare 8V Cylinder Head Shell (No Valve Train)
|
11100-57802
|
Empty aluminum head for remanufacturing
|
|
Bare 16V Cylinder Head Shell (No Valve Train)
|
11100-57B02
|
DOHC bare head housing
|
|
SOHC Single Camshaft (8V Version)
|
12710-60A00
|
Single overhead cam for 8-valve G16A
|
|
DOHC Intake Camshaft (16V Version)
|
12710-58B00
|
Intake cam for 16-valve G16A/G16B
|
|
DOHC Exhaust Camshaft (16V Version)
|
12720-58B00
|
Exhaust cam matched with intake cam
|
|
Single Intake Valve
|
12911-60B00
|
Standard size intake valve, universal for G16A
|
|
Single Exhaust Valve
|
12912-60B00
|
Standard size exhaust valve
|
|
Universal Valve Stem Oil Seal (Intake & Exhaust)
|
09289-52001
|
Single seal for each valve stem
|
|
Inner & Outer Valve Spring Set (Per Valve)
|
12921-60B00
|
Dual spring assembly
|
|
Full Cylinder Head Bolt Kit (10 Pcs Torque-to-Yield)
|
09103-60A01
|
One-time use stretch head bolts
|
|
Valve Guide Sleeve
|
11131-60B00
|
Replacement guide for engine overhaul
|
|
Part Name
|
OEM Number
|
Remarks
|
|
Complete Forged Crankshaft Assembly
|
12221-60A00
|
Exclusive G16A crankshaft, not interchangeable with G13B
|
|
Standard Main Bearing Set (STD, 5 Pairs Upper & Lower)
|
12300-60A00
|
Full set crankshaft main bearings
|
|
Crankshaft Thrust Washer Set
|
12305-60A00
|
Axial positioning thrust shims
|
|
Single Complete Connecting Rod
|
12160-60A00
|
4 forged connecting rods for 4 cylinders
|
|
Standard Connecting Rod Bearing (STD Single Pair)
|
12170-60A00
|
Big end bearing for single connecting rod
|
|
Connecting Rod Bolt (Single Fastener)
|
09104-60A01
|
High tensile rod cap bolt
|
|
STD Complete Piston (With Wrist Pin & Circlip)
|
12111-61A00-000
|
Flat-top STD piston for G16A 8V/16V
|
|
Single Cylinder Piston Ring Set (3 Rings)
|
12140-60A50
|
2 compression rings + 1 oil control ring
|
|
Piston Wrist Pin
|
12151-60A00
|
Pin connecting piston and connecting rod
|
|
Part Name
|
OEM Number
|
Remarks
|
|
Full Engine Overhaul Gasket Kit (8V SOHC)
|
11400-60811
|
Includes oil pan gasket, front/rear crankshaft seals, all small gaskets
|
|
Full Engine Overhaul Gasket Kit (16V DOHC)
|
11400-71812
|
Full set for 16-valve G16A/G16B
|
|
Valve Grind Top Gasket Set (Cylinder Head Only)
|
11400-61812
|
Only for head disassembly, excludes oil pan gasket
|
|
MLS Multi-Layer Steel Cylinder Head Gasket
|
11141-60A00
|
Reinforced metal head gasket
|
|
Rubber Valve Cover Gasket
|
11189-60B00
|
Full perimeter valve cover seal
|
|
Intake Manifold Gasket Set
|
13119-60B00
|
Twin runner intake manifold gasket kit
|
|
Exhaust Manifold Gasket
|
14140-60B00
|
Single exhaust manifold sealing gasket
|
|
Front Crankshaft Oil Seal (Timing Gear Side)
|
09283-52002
|
Timing end crankshaft oil seal
|
|
Rear Main Crankshaft Oil Seal (Flywheel Side)
|
09283-60B01
|
Large rear crankshaft oil seal
|
|
Oil Pan Rubber Gasket
|
11138-60B00
|
Seal gasket for stamped steel oil pan
|
|
Part Name
|
OEM Number
|
Remarks
|
|
Primary Timing Chain
|
12761-60A00
|
Silent timing chain connecting crankshaft & camshaft
|
|
Hydraulic Timing Chain Tensioner
|
12831-60A00
|
Automatic hydraulic chain adjuster
|
|
Timing Chain Guide & Damper Rail Kit
|
12811-60A00
|
Upper & lower sliding timing guides
|
|
Complete Engine Oil Pump Assembly
|
16100-60815
|
Front-mounted rotor oil pump with pressure regulator valve
|
|
Camshaft Front Oil Seal
|
09289-52002
|
Oil seal for camshaft front end
|
G16A 8V fitted for early Suzuki Vitara / Escudo / Sidekick; G16A 16V for Baleno / Cultus for Southeast Asia, Europe & South American export markets.
