Part Name
|
OEM Number
|
Remarks
|
|
Complete Assembled Cylinder Head (With Camshaft, Valves, Rocker Arms)
|
11110-57802
|
Full pre-assembled 16V SOHC head, core OEM for G16B
|
|
Bare Cylinder Head Shell (No valve train assembly)
|
11100-57B02
|
Empty aluminum head casting mark 57B for remanufacturing
|
|
Alternative Bare Head OEM
|
11100-71C01
|
Updated version compatible with late G16B models
|
|
SOHC Single Camshaft Assembly
|
12710-60A00
|
Exclusive camshaft for G16B 16-valve engine
|
|
Single Intake Valve
|
12911-60B00
|
Standard size intake valve
|
|
Single Exhaust Valve
|
12912-60B00
|
Standard size exhaust valve
|
|
Universal Valve Stem Oil Seal (Intake & Exhaust)
|
09289-52001
|
Single seal for each valve stem
|
|
Inner & Outer Dual Valve Spring Set (Per Valve)
|
12921-60B00
|
Complete spring assembly
|
|
Full Torque-to-Yield Cylinder Head Bolt Kit (10 Pcs)
|
09103-60A01
|
One-time use stretch head bolts
|
|
Valve Guide Sleeve Replacement
|
11131-60B00
|
Overhaul spare part for worn guides
|
|
Part Name
|
OEM Number
|
Remarks
|
|
Complete Cast Crankshaft Assembly
|
12221-62G00
|
G16B exclusive crankshaft, not interchangeable with G16A early 8V
|
|
Standard Main Bearing Full Set (STD, 5 pairs upper & lower)
|
12300-62G00
|
Crankshaft main bearings complete kit
|
|
Crankshaft Thrust Washer Shim Set
|
12305-62G00
|
Axial positioning washers for crankshaft
|
|
Single Complete Forged Connecting Rod
|
12160-62G00
|
4 rods total for four cylinders
|
|
Standard Connecting Rod Bearing (STD single pair)
|
12170-62G00
|
Big end bearing for single connecting rod
|
|
Connecting Rod Cap Bolt (Single Fastener)
|
09104-60A01
|
High tensile rod bolt
|
|
STD Complete Piston (With wrist pin & circlip)
|
12100-71820-000
|
Flat-top standard piston for G16B
|
|
Single Cylinder Piston Ring Set (3 rings)
|
12140-60A50
|
2 compression rings + 1 oil control ring
|
|
Piston Wrist Pin
|
12151-60A00
|
Pin connecting piston and connecting rod
|
|
Part Name
|
OEM Number
|
Remarks
|
|
Full Engine Overhaul Gasket Kit (All upper & lower seals)
|
11400-71812
|
Contains oil pan gasket, front/rear crankshaft oil seals & all small gaskets
|
|
Valve Grind Top Gasket Set (Cylinder head only)
|
11400-61812
|
Only for head disassembly, excludes oil pan gasket
|
|
MLS Multi-Layer Steel Cylinder Head Gasket
|
11141-71C00
|
Reinforced metal head gasket for G16B
|
|
Rubber Valve Cover Gasket
|
11189-60B00
|
Full perimeter valve cover sealing gasket
|
|
Integrated Intake Manifold Gasket Set
|
13119-60B00
|
Twin runner intake manifold gasket kit
|
|
Exhaust Manifold Gasket
|
14140-60B00
|
Single exhaust manifold sealing gasket
|
|
Front Crankshaft Oil Seal (Timing Gear Side)
|
09283-52002
|
Timing end crankshaft oil seal
|
|
Rear Main Crankshaft Oil Seal (Flywheel Transmission Side)
|
09283-60B01
|
Large rear crankshaft oil seal
|
|
Oil Pan Rubber Gasket
|
11138-60B00
|
Seal gasket for stamped steel oil pan
|
|
Part Name
|
OEM Number
|
Remarks
|
|
Primary Silent Timing Chain
|
12761-62G00
|
Timing chain connecting crankshaft & camshaft
|
|
Hydraulic Timing Chain Tensioner
|
12831-60A00
|
Automatic hydraulic chain adjuster
|
|
Timing Chain Guide & Damper Rail Kit
|
12811-60A00
|
Upper & lower sliding timing guides
|
|
Complete Engine Oil Pump Assembly
|
16100-62G10
|
Front-mounted rotor oil pump with pressure regulator valve
|
|
Camshaft Front End Oil Seal
|
09289-52002
|
Oil seal for camshaft front journal
|
G16B SOHC 16V fitted for Suzuki Baleno SY416, Vitara / Sidekick / Geo Tracker, Esteem / Cultus Crescent for Southeast Asia, Europe & North American export markets.
