Core Parameter Summary Table
Table Parameter Item Value Displacement 1598cc (1.6L) Cylinder Layout Inline 4-cylinder DOHC 16-valve Valve Train Timing Chain (No Replacement Required) Core Technology Dual VVT-i Variable Valve Timing for Intake and Exhaust
Bore × Stroke 80.5mm × 78.5mm Compression Ratio 10.2:1 Maximum Power 90kW/6000rpm (122Ps) Maximum Torque 154N·m/5200rpm Fuel Supply Multi-point Injection MPI Recommended Fuel 92# Gasoline
Emission Rating China IV / China V Domestic Compatible Models FAW Toyota Corolla EX (2007–2013 1.6L) FAW Toyota Corolla ZRE150 (2007–2014), ZRE180 (2014–2019) 1.6L; FAW Toyota Vios XP90 (2008–2013) 1.6L; Toyota Auris, Corolla Altis (Southeast Asia/Europe version)
