Toyota 1ZZ-FE Engine

The 1ZZ-FE is Toyota’s legendary 1.8L naturally aspirated four-cylinder household engine equipped with VVT-i technology. Its lightweight all-aluminum construction balances outstanding fuel economy and long service life. Widely installed on Toyota Corolla, MR2 Spyder and multiple compact vehicles across global markets, it is recognized as a benchmark powertrain for daily commuting due to outstanding reliability.

MSRP:$0
Was:$0
Now: $0

  • Fast Ground Shipping

  • Free Exchanges

  • Safe Payments

  • Top Selection

Key Parameter Table

Parameter Item Specification
Displacement 1794 cc (1.8 L)
Cylinder Layout Inline 4-cylinder, DOHC 16-valve
Valve Train Drive Maintenance-free timing chain
Core Technology Intake VVT-i variable valve timing
Bore × Stroke 79 mm × 91.5 mm
Compression Ratio 10.0:1
Maximum Power 92–107 kW / 6000–6400 rpm (125–145 hp)
Peak Torque 161–171 N·m / 4200 rpm
Fuel Supply System Multi-point fuel injection (MPFI)
Recommended Fuel Grade 92-octane gasoline
Emission Standard Euro IV

Global Vehicle Applications

  1. FAW Toyota Corolla EX (2001–2007, China market)
  2. Toyota Corolla E110/E120, Corolla Altis (Asia, North America, Europe)
  3. Toyota MR2 Spyder W30 (2000–2005, lightweight roadster)
  4. Toyota Avensis T220/T250
  5. Toyota Allion, Premio, Caldina (Japan domestic market)
  6. Toyota Matrix / Pontiac Vibe (North America joint model)
  7. Toyota Celica GT, Corolla Verso, Wish
