Toyota 5AR-FE Engine

The 5AR-FE is a China-exclusive 2.5L naturally aspirated four-cylinder engine upgraded from Toyota’s mature AR platform, fitted with Dual VVT-i and ACIS variable intake technology. Its all-aluminum lightweight structure and port injection design balance sufficient power output, daily fuel economy and easy maintenance. Widely mounted on Camry, RAV4 and Harrier sold in China, it is recognized as a stable, cost-effective mid-displacement household powertrain.

MSRP:$0
Was:$0
Now: $0

  • Fast Ground Shipping

  • Free Exchanges

  • Safe Payments

  • Top Selection

Parameter Item Specification
Displacement 2494 cc (2.5 L)
Cylinder Layout Inline 4-cylinder, DOHC 16-valve
Valve Train Drive Maintenance-free timing chain
Core Technology Dual VVT-i + ACIS variable intake manifold
Fuel Supply System Multi-point fuel injection (MPI)
Bore × Stroke 90 mm × 98 mm
Compression Ratio 10.4:1
Maximum Power 135 kW / 6000 rpm (184 hp)
Peak Torque 235 N·m / 4100 rpm
Recommended Fuel Grade 92-octane gasoline
Emission Standard China National IV / V
Production Period 2013–2017
Engine Oil Capacity 4.4 L (with filter), recommended 5W-30

Vehicle Applications (Chinese Market Only)

  1. Toyota Camry XV50 (2015–2017 2.5L variants)
  2. Toyota RAV4 XA40 (2013–2018 2.5L models)
  3. Toyota Harrier XU60 (2013–2017 2.5L SUV)
