Toyota 5NR-FE Engine

The 5NR-FE is a China-exclusive lightweight 1.5L naturally aspirated four-cylinder engine with Dual VVT-i technology, based on Toyota’s mature NR platform. Its full-aluminum construction and long-stroke design achieve an excellent balance of daily power output and outstanding fuel economy. Widely fitted on Vios and Yaris L sold in China, it is recognized as a cost-effective, durable powertrain for urban compact commuter vehicles.

MSRP:$0
Was:$0
Now: $0

  • Fast Ground Shipping

  • Free Exchanges

  • Safe Payments

  • Top Selection

Parameter Item Specification
Displacement 1496 cc (1.5 L)
Cylinder Layout Inline 4-cylinder, DOHC 16-valve
Valve Train Drive Maintenance-free timing chain
Core Technology Dual VVT-i intake & exhaust variable valve timing
Fuel Supply System Sequential multi-point fuel injection (SFI)
Bore × Stroke 72.5 mm × 90.6 mm
Compression Ratio 10.5:1
Maximum Power 79–82 kW / 6000 rpm (107–110 hp)
Peak Torque 138–140 N·m / 4200 rpm
Recommended Fuel Grade 92-octane gasoline
Emission Standard China National V / VI
Production Period 2013 – Present
Recommended Engine Oil 0W-20 full synthetic oil

Vehicle Applications (Chinese Market Only)

  1. Toyota Vios NCP150 (all 1.5L generations)
  2. Toyota Yaris L Sedan & Hatchback 1.5L variants
