| Part Name | OEM Number | Remarks |
|---|---|---|
| Complete Left Cylinder Head (With Camshaft & Valves) | 12100-R70-A00 | Bank 1 (Cylinder 1-3), Casting Mark R70 |
| Complete Right Cylinder Head (With Camshaft & Valves) | 12200-R70-A00 | Bank 2 (Cylinder 4-6), Casting Mark R70 |
| Bare Left Cylinder Head (No Valve Train) | 12100-R70-A01 | For Remanufacturing Replacement |
| Bare Right Cylinder Head (No Valve Train) | 12200-R70-A01 | For Remanufacturing Replacement |
| Intake Camshaft (Left & Right Interchangeable) | 14100-R70-A01 | Matched with VCM Variable Cam Mechanism |
| Exhaust Camshaft (Left & Right Interchangeable) | 14200-R70-A01 | Substitute OE: 14200-R70-A11 |
| Intake Valve (Single Unit) | 14711-R70-A00 | Original Single Intake Valve |
| Exhaust Valve (Single Unit) | 14721-R70-A00 | Original Single Exhaust Valve |
| Valve Oil Seal (Single, Intake & Exhaust Universal) | 12210-R70-A01 | Universal Seal for All Valves |
| Valve Spring Assembly | 14751-R70-A00 | Inner & Outer Spring Set |
| Valve Guide | 12231-R70-A00 | Replacement Part for Engine Overhaul |
| Full Cylinder Head Bolt Kit (12 Pcs) | 90004-R70-A00 | Complete Set of Head Fasteners |
| Part Name | OEM Number | Remarks |
|---|---|---|
| Complete Crankshaft Assembly | 13310-R70-A00 | Forged Crankshaft Exclusive to J35Z2, Matched with Balance Shaft System |
| Standard Main Bearing Set (STD Size, 6 Pairs) | 13315-R70-A00 | Upper & Lower Main Bearings Full Set |
| Crankshaft Thrust Washer | 13316-R70-A00 | Axial Positioning Shim for Crankshaft |
| Single Complete Connecting Rod | 13210-R70-A00 | Universal for All 6 Cylinders, Interchangeable OE: 13210-RZP-000 |
| Standard Connecting Rod Bearing (STD Size, Single Pair) | 13215-R70-A00 | Big End & Small End Bearing Pair |
| Connecting Rod Bolt (Single) | 90014-R70-A00 | Fastening Bolt for Connecting Rod |
| Standard Complete Piston (With Pin & Circlip, STD Size) | 13010-R70-A00 | Single Piston Assembly, Interchangeable OE: 13010-RZP-A00 |
| Piston Ring Set (Single Cylinder, 3 Rings) | 13030-R70-A00 | 2 Compression Rings + 1 Oil Control Ring |
| Piston Wrist Pin | 13041-R70-A00 | Pin Connecting Piston & Connecting Rod |
| Complete Balance Shaft Assembly | 13400-R70-A00 | Dual Balance Shaft Unit Installed at Bottom of Block |
| Part Name | OEM Number | Remarks |
|---|---|---|
| Full Engine Overhaul Gasket Kit (All Upper & Lower Seals) | 06110-R70-A00 | Includes Oil Pan Gasket, Front/Rear Crankshaft Oil Seals & All Small Gaskets |
| Valve Grind Top Gasket Set (Cylinder Head Only) | 06120-R70-A00 | Only for Cylinder Head Disassembly, Excludes Oil Pan Gasket |
| Left MLS Cylinder Head Gasket (Bank 1) | 12251-R70-A01 | Multi-Layer Steel Head Gasket |
| Right MLS Cylinder Head Gasket (Bank 2) | 12252-R70-A01 | Multi-Layer Steel Head Gasket |
| Valve Cover Gasket (Left / Right, 1 Pc Each Side) | 12341-R70-A01 | Rubber Seal Gasket for Each Cylinder Head Cover |
| Upper & Lower Intake Manifold Gasket Set | 17105-R70-A00 | Split Gaskets for Dual Section Intake Manifold |
| Exhaust Manifold Gasket (3 Cylinders Per Side) | 18115-R70-A00 | One Gasket for Each Bank Exhaust Pipe |
| Front Crankshaft Oil Seal (Timing Side) | 91212-R70-A01 | Oil Seal at Timing Gear End |
| Rear Crankshaft Oil Seal (Transmission Flywheel Side) | 91214-R70-A01 | Large Oil Seal at Flywheel Housing |
| Oil Pan Gasket | 11251-R70-A01 | Seal Gasket for Aluminum Oil Pan |
| Part Name | OEM Number | Remarks |
|---|---|---|
| Primary Timing Chain | 14401-R70-A00 | Main Chain Connecting Crankshaft & Camshafts |
| Hydraulic Timing Chain Tensioner | 14510-R70-A01 | Automatic Hydraulic Chain Adjuster |
| Timing Chain Guide & Damper | 14530-R70-A00 | Upper & Lower Timing Sliding Guides |
| Complete Oil Pump Assembly | 15100-R70-A00 | Front Mount Oil Pump With Pressure Regulator Valve |
| Oil Pump Drive Chain | 15131-R70-A00 | Small Chain Driving Oil Pump |
| VCM Variable Cylinder Solenoid Valve | 28200-R70-A01 | Hydraulic Solenoid for Cylinder Deactivation Switch |
| VVT Oil Control Valve / Camshaft Position Sensor Valve | 15830-R70-A01 | Oil Pressure Control Valve for Variable Valve Timing |
