Part Name
|
OEM Number
|
Remarks
|
|
Complete Cylinder Head Assembly (With Camshafts & Valves)
|
10003-PPA-A02
|
Full assembled head, casting mark PPA
|
|
Bare Cylinder Head (No Valve Train)
|
11000-PPA-A00
|
Empty cylinder head shell for remanufacturing
|
|
Intake Camshaft
|
14110-PPA-000
|
i-VTEC intake camshaft, variable lift mechanism
|
|
Exhaust Camshaft
|
14210-PPA-000
|
Exhaust camshaft, interchangeable with K24A4
|
|
Single Intake Valve
|
14711-PNA-000
|
Standard size intake valve
|
|
Single Exhaust Valve
|
14721-PNA-000
|
Standard size exhaust valve
|
|
Universal Valve Oil Seal (Intake & Exhaust)
|
12210-PPA-003
|
Single valve stem oil seal
|
|
Valve Spring Assembly (Inner + Outer)
|
14751-PPA-000
|
Complete spring set per valve
|
|
Cylinder Head Bolt Full Kit (10 Pcs)
|
90004-PPA-A00
|
Torque-to-yield head bolt set
|
|
Valve Guide Sleeve
|
12231-PPA-000
|
Replacement valve guide for overhaul
|
|
Part Name
|
OEM Number
|
Remarks
|
|
Complete Forged Crankshaft Assembly
|
13310-RAA-A00
|
K24A8 exclusive crankshaft, 87mm bore / 99mm stroke
|
|
Standard Main Bearing Set (STD, 5 pairs)
|
13315-PPA-000
|
Upper & lower crankshaft main bearings
|
|
Crankshaft Thrust Washer Set
|
13316-PPA-000
|
Axial positioning thrust shims
|
|
Single Complete Connecting Rod
|
13210-PPA-A00
|
4 rods total for 4 cylinders, casting PPA
|
|
Standard Connecting Rod Bearing (STD Single Pair)
|
13215-PPA-000
|
Big end bearing for connecting rod
|
|
Connecting Rod Bolt (Single)
|
90014-PPA-A00
|
Fastening bolt for connecting rod cap
|
|
STD Complete Piston (With Pin & Circlip)
|
13010-RAA-A01
|
Dish-top piston for K24A8 i-VTEC
|
|
Piston Ring Set (Single Cylinder, 3 Rings)
|
13030-RAA-A00
|
2 compression rings + 1 oil control ring
|
|
Piston Wrist Pin
|
13041-PPA-000
|
Pin connecting piston and connecting rod
|
|
Part Name
|
OEM Number
|
Remarks
|
|
Full Engine Overhaul Gasket Kit (All Upper & Lower Seals)
|
06110-PPA-A010
|
Includes oil pan gasket, front/rear crankshaft oil seals, all small gaskets
|
|
Valve Grind Top Gasket Set (Cylinder Head Only)
|
06120-PPA-A00
|
Only for cylinder head disassembly, excludes oil pan gasket
|
|
MLS Multi-Layer Steel Cylinder Head Gasket
|
12251-RAA-A01
|
Reinforced metal head gasket
|
|
Rubber Valve Cover Gasket
|
12341-PPA-000
|
Full perimeter valve cover seal
|
|
Intake Manifold Gasket Set (4 Runner Gaskets)
|
17105-PPA-000
|
Full set for single-piece intake manifold
|
|
Exhaust Manifold Gasket
|
18115-PPA-000
|
Single exhaust manifold gasket
|
|
Front Crankshaft Oil Seal (Timing Side)
|
91212-PPA-003
|
Timing gear end oil seal
|
|
Rear Main Crankshaft Oil Seal (Flywheel Side)
|
91214-PPA-003
|
Large rear crank seal at transmission housing
|
|
Oil Pan Gasket
|
11251-PPA-000
|
Aluminum oil pan rubber seal gasket
|
|
Part Name
|
OEM Number
|
Remarks
|
|
Primary Timing Chain
|
14401-PPA-000
|
Main timing chain connecting crankshaft & camshafts
|
|
Hydraulic Timing Chain Tensioner
|
14510-PPA-003
|
Automatic hydraulic chain adjuster
|
|
Timing Chain Guide & Damper Rail Kit
|
14530-PPA-000
|
Upper & lower sliding timing guides
|
|
Complete Engine Oil Pump Assembly
|
15100-RAA-A02
|
Front-mounted oil pump with pressure regulator valve
|
|
Oil Pump Drive Small Chain
|
15131-PPA-000
|
Short chain driving oil pump gear
|
|
i-VTEC Oil Control Solenoid Valve (OCV)
|
15830-PPA-A01
|
Variable valve timing hydraulic control valve
|
K24A8 factory fitted for 2006–2007 Honda Accord CM5 2.4L, 2007–2009 Honda Element; Compatible partial CR-V RE4 models for overseas export market.
